Features:

Model HGW8500CX(E)
Frequency(HZ) 50
Cont.AC output(KVA) 6.0
Max.AC output(KVA) 6.5
Cont.Voltage(V) 115/230;220;230;240
Phase Number Single-Phase
Insulation F
Power factor (cos?) 1
DC Output(V/A) 12/8.3
No-load Vp:tage(DC)(V) 50
Cont.Current(DC)(V) 180
Cont.Rated Voltage(DC)(V) 25-35
Continuous load Rate(A) 60%
Continuous load Rate(A) 80-210
Model HG190F(E)
Type OHV 4-Stroke air-cooled single-cylinder
Displacement 420
Engine Speed(rpm) 3000
Starting System Recoil or Recoil/Electric
Max.power Output(hp) 15
Fuel Tank capacity(L) 25
Operational Capacity(hr) 7.5
Operating Noise Level(at 7m) 72
DIM (LxWxH)(mm) 685?510?550
Net weight(kg) 87/91?E)

Model HGW12000CXE
Frequency(HZ) 50
Cont.AC output(KVA) 10
Max.AC output(KVA) 11
Cont.Voltage(V) 115/230;220;230;240
Phase Number Single-Phase
Insulation F
Power factor (cos?) 1
DC Output(V/A) 12/8.3
No-load Vp:tage(DC)(V) 70
Cont.Current(DC)(V) 240
Cont.Rated Voltage(DC)(V) 25-60
Continuous load Rate(A) 60%
Continuous load Rate(A) 80-320
Model B&S690
Type 2V 4-Stroke air-cooled single-cylinder
Displacement 690
Engine Speed(rpm) 3000
Starting System Electric
Max.power Output(hp) 22
Fuel Tank capacity(L) 25
Operational Capacity(hr) 6
Operating Noise Level(at 7m) 72
DIM (LxWxH)(mm) 900?650?660
Net weight(kg) 153
